Type | router |
Interface | 10/100 Ethernet /1 порт WAN |
1х 10/100 Ethernet /2 порта LAN | |
The number of antennas | 4 pcs |
Frequency band | 2.4 GHz + 5 GHz |
Remote control | Access control |
DHCP | |
local control | |
remote control | |
Features | WMM (Wi-Fi QoS) |
DHCP Server/Client | |
Turning on/off wireless broadcasting | |
DMZ | |
DHCP server | |
Dimensions | 114 × 26 × 94 mm |
Type | router |
Interface | 10/100 Ethernet /1 порт WAN |
1х 10/100 Ethernet /2 порта LAN | |
Modes of operation | router mode |
access point |
Standards | IEEE 802.11b |
IEEE 802.11a | |
IEEE 802.11g | |
IEEE 802.11n | |
IEEE 802.11ac | |
IEEE 802.11 communication standard | a/b/g/n/ac |
The number of antennas | 4 pcs |
Frequency band | 2.4 GHz + 5 GHz |
Wireless mode functions | Turning on/off wireless broadcasting |
Maximum connection speed | 867 Mbps (на 5 ГГц; 300 Мбіт/с на 2,4 ГГц) |
Remote control | Access control |
DHCP | |
local control | |
remote control |
The input interface (WAN) | PPPoE |
PPTP | |
L2TP | |
PPTP/L2TP | |
DHCP | |
Dynamic IP address | |
Static IP address | |
Firewall Security | SPI |
Binding by IP and MAC addresses | |
Supported protocols | IPv4 |
IPv6 | |
DHCP Server | |
DHCP client | |
Reset button to factory defaults |
![]() |
Security features | WEP |
WPA3-Personal | |
WPA2-Personal | |
WPA-Personal | |
SPI firewall | |
Certification | RoHS |
CE | |
Features | WMM (Wi-Fi QoS) |
DHCP Server/Client | |
Turning on/off wireless broadcasting | |
DMZ | |
DHCP server | |
Equipment | Power adapter |
Quisk start guide | |
router | |
Ethernet cable | |
Additional information | DHCP server |
DHCP | |
DNS | |
uPnP |
Tested ambient temperature | 0 °C - 40 °C |
Allowable relative operating humidity | 10–90 % |
Allowable relative storage humidity | 5–90 % |
Dimensions | 114 × 26 × 94 mm |
Width | 240 mm |
Height | 60 mm |
Length | 170 mm |
Weight | 0.39 kg |
Volume | 0.0024 m3 |
Warranty | 3 years |
AC1200 Wireless Dual Band Router
Complying with the powerful 802.11ac standard, AC10 delivers blazing-fast Wi-Fi speeds up to 1200 Mbps, which is 3× faster than the speed of the previous 802.11n standard. Choose the 300 Mbps (2.4 GHz) for internet surfing, email, and social media or 867 Mbps (5 GHz) for bandwidth-intensive tasks like HD streaming and gaming.
Four external 5dBi antennas powered with advanced antenna technology provide users with larger wireless coverage throughout your home or office. With the combination of Beamforming Technology, the AC10 can detect the location of your connected devices and concentrate wireless signal strength towards them, making your connection more stable.
With MU-MIMO, AC10 communicates with multiple devices at the same time to allow connected devices to achieve faster speeds than standard AC routers, increasing overall network throughput.
With no need for complicated configuration, you can simply follow the step-by-step instructions on the intuitive webpage to set up your AC10 in minutes.
IGMP Proxy/Snooping, Bridge, and Tag VLAN technology allow your streaming activities to pass through fast LAN ports, optimizing Hi-Resolution videos.
Supervise children (or even staff) by limiting access. Manage when and how connected devices can access
the internet.
Allow guests to join your Wi-Fi network—all while protecting your privacy. This makes sharing easy and secure.
WPA/WPA2 encryption standards create an active defense against security threats and intruders.
Allows you to enjoy IPv6 services provided by your ISP and visit IPv6 websites
Access Point Mode, Range Extender Mode, and Router Mode supported to satisfy all application scenarios
Prioritizes devices you select to perform better
