Samsung Hanwha Techwin NVR XRN-815S, 8ch, 2HDD, 8PoE/PoE+, 12MP~CIF, P2P

SKU: XRN-815S
New
Previous
Next
Technical characteristics Samsung Hanwha Techwin NVR XRN-815S, 8ch, 2HDD, 8PoE/PoE+, 12MP~CIF, P2P:
Main features
Full list of features
Type IP video recorder
Video compression method MJPEG
H.264
H.265
Audio compression method G.726
AAC /(16/48 KHz)
G.711
Media Type SATA
Maximum capacity of disks 20 Tb
Basic
Type IP video recorder
Type of connected cameras 12Mp IP cameras
Video compression method MJPEG
H.264
H.265
Audio compression method G.726
AAC /(16/48 KHz)
G.711
Media Type SATA
Maximum capacity of disks 20 Tb
Features Power, Record, Network indication
Inputs / Outputs
Number of USB 2.0 inputs 2 (фронтальні, 1 x USB 3.0 задній)
Ethernet 1 x RJ-45 (WAN, 1 Gbps)
8 x RJ-45 PoE+ (LAN, 10/100)
Additionally
Power Consumption 165 W (563 BTU з 2HDD, PoE увімкнено)
Operating temperature 0-40 °С
Operating humidity 20-85 %
Physical
Width 320 mm
Height 50.7 mm
Length 370 mm
Weight 2.86 kg
Gross size
Width 410 mm
Height 150 mm
Length 490 mm
Weight 4.15 kg
Volume 0.0301 m3
Warranty
Warranty 36 months
Hanwha XRN-815S is an 8-channel NVR supporting up to 12MP cameras with a total recording bandwidth of 100 Mbps. It features 8 PoE/PoE+ ports for direct camera connection and 2 SATA slots for up to 20TB storage.
41700 UAH*
in stock
* Recommended retail price
Where to buy: Samsung Hanwha Techwin NVR XRN-815S, 8ch, 2HDD, 8PoE/PoE+, 12MP~CIF, P2P:
Comtrading
Видеорегистратор Hanwha XRN-815S, 8ch, 2HDD, 8PoE/PoE+, 12MP~CIF, P2P
  • H.265, H.264, MJPEG codec
  • AI Search: Object Attribute (When integrated with Wisenet AI Camera)
  • 100Mbps network camera recording
  • Plug & play by 8 PoE(LAN, 10/100), 1PoE(WAN, 1Gbps)
  • SATA 2ea(up to 20TB)
  • ARB supported
  • P2P service (QR code connect) supported
