| У напрямку | геймерська (overclocking) |
| Форм-фактор | ATX |
| Тип підключення | LGA1700 |
| Процесорна сумісність | Intel Core 13th Generation |
| Intel Core 12th Generation | |
| Intel Core 14th Generation | |
| Північний міст (чіпсет) | Z790 |
| UEFI BIOS |
|
| Максимальний обсяг пам'яті | 256 ГБ |
| Звук | 7.1 |
| 5.1 | |
| 2 | |
| 4 | |
| Підтримка програмного RAID |
0/1/5/10
|
| SATA3 (6 Гбіт / с) | 4 порти |
| LAN (RJ-45) | 100/1000/2500 Мбіт/с |
| USB 2.0 | 6 шт (Chipset: 2 на задній панелі; Chipset+USB 2.0 Hub: 4 доступні через внутрішній USB роз'єм) |
| PS/2 | 1 шт (клавіатура/миша) |
| Основний роз'єм живлення | 24-контактний |
| Живлення процесора | 8-контактне /x2 |
| Розміри ( ВхШ ) | 305 x 244 мм |
| У напрямку | геймерська (overclocking) |
| Форм-фактор | ATX |
| Для процесорів | Intel |
| Тип підключення | LGA1700 |
| Процесорна сумісність | Intel Core 13th Generation |
| Intel Core 12th Generation | |
| Intel Core 14th Generation |
| Північний міст (чіпсет) | Z790 |
| BIOS | UEFI |
| UEFI BIOS |
|
| Тип роз'єму | DDR5 |
| DDR5 | 4 слоти |
| Максимальна тактова частота | 7600 МГц |
| Максимальний обсяг пам'яті | 256 ГБ |
| Графічний інтерфейс | PCI-E x16 4.0 |
| PCI-E x16 3.0 | |
| PCI-E x1 3.0 | |
| PCI-E x16 5.0 | |
| Вихід HDMI |
|
| Display Port |
|
| Аудіочіп | Realtek® |
| Звук | 7.1 |
| 5.1 | |
| 2 | |
| 4 | |
| S/P-DIF |
|
| Інтерфейс підключення | SATA 3 |
| M.2 | |
| Підтримка програмного RAID |
0/1/5/10
|
| SATA3 (6 Гбіт / с) | 4 порти |
| LAN (RJ-45) | 100/1000/2500 Мбіт/с |
| Кількість LAN-портів | 1 |
| Модель LAN-контролера | Realtek 2.5GbE |
| USB 2.0 | 6 шт (Chipset: 2 на задній панелі; Chipset+USB 2.0 Hub: 4 доступні через внутрішній USB роз'єм) |
| PS/2 | 1 шт (клавіатура/миша) |
| USB 3.2 Gen 1 | 7 /(Chipset: 1xType-C, доступний через внутрішній USB роз'єм; 4 на задній панелі, 2 доступні через внутрішній USB роз'єм) |
| USB 3.2 Gen 2 | 2 /(Chipset: 1xType-C на задній панелі, 1 x Type-A (червоний) на задній панелі) |
| M.2 роз'єм | 3 |
| Особливості | S/PDIF out header |
| Thunderbolt™ AIC Connector | |
| CPU fan header | |
| system fan headers | |
| clear CMOS jumper | |
| iTE I/O Controller Chip | |
| reset button | |
| Front panel audio connector | |
| Support for Windows 10 64-bit | |
| Q-Flash Plus button | |
| Функція Smart Backup | |
| Утиліта Q-Flash | |
| Front Panel Header | |
| Addressable LED Header | |
| Voltage detection | |
| Temperature detection | |
| Fan speed detection | |
| Fan fail warning | |
| Fan speed control | |
| system fan/water cooling pump header | |
| Утиліта Q-Flash Plus | |
| Water cooling flow rate detection | |
| Support for Windows 11 64-bit | |
| Internet Security | |
| LAN bandwidth management software |
| Основний роз'єм живлення | 24-контактний |
| Живлення процесора | 8-контактне /x2 |
| Розміри ( ВхШ ) | 305 x 244 мм |
| Ширина | 270 мм |
| Висота | 80 мм |
| Довжина | 340 мм |
| Вага | 1.61 кг |
| Об'єм | 0.0073 м3 |
| Гарантія | 36 місяців |
GIGABYTE Ultra Durable motherboards built with optimal components inside out provide the prime performance and timeless platform.
Digital VRM Design
The best VRM design ever built with the highest quality components.
Unlock DDR5
DDR5 Overclocking Up to 7600 and Beyond
GIGABYTE is offering a tested and proven platform with extreme memory performance boost.
Future Connectivity
The ultimate connectivity with blazing data-transfer speeds through the next generation network and storage.
2.5GbE LAN
Supercharge your gaming with 2.5GbE LAN Achieve lightning-fast speeds, minimal lag, and unbeatable performance to elevate your gaming setup and dominate the competition.
PCIe 5.0 / 4.0 Hardware Design
Featuring PCIe 5.0 x16 slot and PCIe 4.0 M.2 slot support, GIGABYTE Motherboards are ready to work with the PCIe 5.0/ 4.0 devices to provide the superior performance.
High-End Audio Capacitors
These high quality capacitors help deliver high resolution and high fidelity audio to provide the most realistic sound effects.
Audio Noise Guard
Essentially separates the board’s sensitive analog audio components from potential noise pollution at the PCB level.
Easy Friendly
Innovative and intuitive hardware, software, and BIOS interface design to create your personal style.
EZ-Latch
Unlock the latch of the PCIe slot easily when remove the graphics card in the PCIe slot.
Q-Flash Plus
Update the BIOS easily without installing the CPU, memory, and graphics card.
